Frame
SLR OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel
-
Fork
Fox Performance 34 Step-Cast, Float EVOL air spring, GRIP 2-position damper, remote lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 110 mm travel
-
Shock
Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper
-
Suspension part
Bontrager Drop Lock remote
-
Max compatible fork travel
120mm, min 100mm
-
Wheel front
Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
-
Wheel rear
NEW Bontrager Kovee Elite 30 carbon, Tubeless Ready, 108T Rapid Drive, 6-bolt, Boost148, 12 mm thru axle, 29"
-
Skewer rear
Bontrager Switch thru axle, removable lever
-
Tyre
Maxxis Aspen, Tubeless Ready, EXO casing, folding bead, 29x2.4"
-
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
-
Rim strip
Bontrager TLR
-
Max tyre size
Frame: 29x2.40", Fork: See manufacturer
-
Shifter
Shimano XT M8100, 12-speed
-
Rear derailleur
Shimano XT M8100, long cage
-
Cassette
Shimano XT M8100, 10-51, 12-speed
-
Chain
Shimano XT M8100, 12-speed
-
Max chainring size
1x: 38T, min 30T
-
Saddle
Bontrager Aeolus Elite, austenite rails, 145 mm width
-
Seatpost
Size: S Bontrager Line Elite Dropper, 100 mm travel, MaxFlow, internal routing, 31.6 mm, 340 mm length
-
Seatpost
Size: M, ML Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 31.6 mm, 440 mm length
-
Seatpost
Size: L, XL Bontrager Line Elite Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 480 mm length
-
Handlebar/stem (integrated)
Size: S, M, ML Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 70 mm length
-
Handlebar/stem (integrated)
Size: L Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 80 mm length
-
Handlebar/stem (integrated)
Size: XL Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 90 mm length
-
Grips
ESI Chunky
-
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
-
Rotor size
Max brake rotor sizes - Frame: 160mm, Fork: see fork manufacturer
-
Tool
Bontrager Switch Lever, w/tool
-
Weight
M - 11.18 kg / 24.65 lbs (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
