Specifications
Highlights
Color
899 Matte, 903 Matte
Fork suspension
Telescope, air
Gear Type
Hub
General
Weight
27 WithoutBattery
Color
899 Matte, 903 Matte
Bike Max. Total Weight (kg)
150
Sitting Position
Active, Upright
Frame & Fork
Frame
Grips
Ergon ErgonGP1L, plastic handlebar grips with ergonomic form for a better distribution of pressure on the hands
Frame description
Stable aluminium frame with 70,5° headset angle and 71,5° saddle tube angle for sporty cycling characteristics. Battery, motor and cables harmoniously integrated into the frame. High-quality finish with attention to detail.
Frame material
Aluminum
Cockpit Cable Integration
Yes
Frame shape
High-Step, Low-Step
Frame sizes
L (57) , M (53) , S (49) , XL (61) , XS (46) , XXL (65)
Frame Size CM
46, 49, 53, 57, 61, 65
Fork
Fork
SRSuntour MOBIE34, AIR
Fork description
AIR
Fork Material
Aluminum
Fork suspension
Telescope, air
Fork lockout
Yes
Wheels & Tires
Wheels
Front wheel
55, Gates
Rear wheel
24, Gates
Front rim
Ryde RydeZac25, double-walled aluminium for extra strong and efficient cycling performance
Rear rim
Ryde RydeZac25, double-walled aluminium for extra strong and efficient cycling performance
Front hub
Shimano
Rear hub
Enviolo EnvioloTrekkingManual
WheelSize Front
28"
Tires
Wheels Tire Front Etrto
55-622
Front tyre
Schwalbe SchwalbeTheGreenMarathon, 80% recycled and renewable materials
Rear tyre
Schwalbe SchwalbeTheGreenMarathon, 80% recycled and renewable materials
Wheels Tire Front Description
80% recycled and renewable materials
Brake & transmission
Gears
Brand shifters
Enviolo
Gear
Enviolo EnvioloTrekking
Shifter
Enviolo EnvioloTwistPure
Gear Type
Hub
Number of gears
Stepless
Drivetrain
Rear brake type
HydrDiscBrake
Front brake
Shimano MT420
Rear brake
Shimano MT420
Front sprocket
55, Gates GatesCDX
Rear sprocket
24, Gates GatesCDX
Front chainwheel
55
Drivetrain
Belt
Crankset Model
Delta
Brakes
Front Brake Type
Hydraulic disc brake
Brake sytem code
SE
Front Brake Brand
Shimano
Primary Rear Brake Model
MT420
Front brake
Shimano MT420, 180
Rear brake
Shimano MT420, 160
Rear Brake Lever
BLMT420
Handlebar & Seat
Handlebar
Handlebar
Ergon ErgonGP1L, plastic handlebar grips with ergonomic form for a better distribution of pressure on the hands
Stem adjustable
Yes
Steering lock
Yes
Cockpit Handlebar Grip Brand
Ergon
Saddle
Saddle
SelleRoyal SREssenzaPlusGel
Seatpost suspension
Yes
Lighting
Front light
Front light
Herrmans HerrmansMR10
Front Light Energy Source
Battery
Front Light Lux
90
Rear light
Rear Light Energy Source
Battery
Rear light
Spanninga SpanningaCommuterGlow
E-bike technology
Engine
Motor
Bosch Smart System Performance Line PX
System Model
Performance Line PX
Ebike System Brand
Bosch Smart System
Ebike Engine Position
Mid
Ebike Max Speed kmh
25
Ebike Max Speed mph
15
Engine Max Torque (Nm)
85
Battery
Charger
Bosch Standard, 4 Ah
Ebike Battery Charger Description
4 Ah
Battery Position
Integrated in the frame
Display
Display
Bosch Kiox 500
Support levels
Eco, Tour, Auto, Turbo
Display Removable
Yes
Ebike Walk Assist
Yes
Display Type
LCDc
Service
Warranty
Frame warranty
10 year's warranty
Fork warranty
5 year's warranty
Paint warranty
5 year's warranty
Other parts warranty
2 year's warranty
Battery warranty
2 year's warranty
Motor warranty
2 year's warranty
Display warranty
2 year's warranty
