Specifications
Highlights
Color
Graphite blue matte, light olive matte
Fork suspension
Telescope, spiral spring
Gear Type
Hub
General
Weight
24.7 excl. battery
Color
Graphite blue matte, light olive matte
Bike Max. Total Weight (kg)
150
Sitting Position
Upright
Frame & Fork
Frame
Frame descriptionLightweight aluminium frame with comfort geometry for stable and comfortable handling. Rear carrier integrated into the frame, low step-through frame with a single down tube for a low spacious step-through. Integrated cable routing.
Frame materialAluminum
Frame shapeHigh-Step, Low-Step
Frame Size CM46, 49, 53, 57, 61, 65
Fork
Fork MaterialAluminum
Fork suspensionTelescope, spiral spring
Fork lockoutNo
Wheels & Tires
Wheels
Front wheel38
Rear wheel18
Front rimRyde ZAC 421, double-walled aluminium for extra strong and efficient cycling performance
Rear rimRyde ZAC 421, double-walled aluminium for extra strong and efficient cycling performance
Front hubShimano
Rear hubShimano Nexus 7
WheelSize Front28"
Tires
Wheels Tire Front Etrto47-622
Front tyreSchwalbe Energizer Active Plus
Rear tyreSchwalbe Energizer Active Plus
Brake & transmission
Gears
Brand shiftersShimano
Gear TypeHub
Number of gears7
Drivetrain
Front chainwheel38
DrivetrainChain
Brakes
Front Brake TypeHydraulic disc brake
Brake sytem codeS7
Front Brake BrandTektro
Primary Rear Brake ModelHD-T280
Front brakeTektro HD-T280, 180 mm
Rear brakeTektro HD-T280, 160 mm
Rear Brake LeverTektro
Handlebar & Seat
Handlebar
HandlebarGazelle Aerowing, plastic wear-resistant handlebar grips for a firm grasp
Stem adjustableYes
Cockpit Handlebar Grip BrandGazelle
Saddle
SaddleSelle Royal
Seatpost suspensionNo
Lighting
Front light
Front lightAXA Blue Line 30
Front Light Energy SourceBattery
Front Light Lux30
Rear light
Rear Light Energy SourceBattery
Rear lightTrelock LS 611
E-bike technology
Engine
System ModelActive Line
Ebike System BrandBosch Smart System
Ebike Engine PositionMid
Ebike Max Speed kmh25
Ebike Max Speed mph15
Engine Max Torque (Nm)40
Battery
ChargerBosch Compact Charger,
Ebike Battery Charger Description2 Ah
Battery PositionIntegrated in the carrier
Display
DisplayBosch Purion 200
Ebike Walk AssistYes
Display TypeLCDc
Service
Warranty
Frame warranty10 year's warranty
Fork warranty5 year's warranty
Paint warranty5 year's warranty
Other parts warranty2 year's warranty
Battery warranty2 year's warranty
Motor warranty2 year's warranty
Display warranty2 year's warranty
