Specifications
Highlights
Color
Pine green gloss, turmeric yellow gloss
Fork suspension
Telescope, spiral spring
Gear Type
Derailleur
Frame & Fork
Frame
Frame descriptionStable lightweight aluminium sloping frame with 70,5° headset angle and 73° saddle tube angle for a sporty posture and precise handling. Cables beautifully integrated into the frame.
Frame materialAluminum
Cockpit Cable IntegrationYes
Frame shapeHigh-Step, Mid-Step
Frame Size CM45, 50, 55, 60
Fork
ForkSR Suntour MOBIE A32 DS
Fork descriptionSuntour MOBIE A32 DS
Fork MaterialAluminum
Fork suspensionTelescope, spiral spring
Fork lockoutYes
Wheels & Tires
Wheels
Front wheel38
Rear wheel
Front rimRyde Big Bull, double-walled aluminium for extra strong and efficient cycling performance
Rear rimRyde Big Bull, double-walled aluminium for extra strong and efficient cycling performance
Front hubShimano
WheelSize Front28"
Tires
Wheels Tire Front Etrto62-584
Front tyreContinental Contact Plus
Rear tyreContinental Contact Plus
Wheels Tire Front DescriptionContinental Contact Plus
Brake & transmission
Gears
Brand shiftersShimano
Cassette Range11-48
Gear TypeDerailleur
Number of gears10
Drivetrain
Rear derailleurShimano Deore
Front chainwheel38
DrivetrainChain
Brakes
Front Brake TypeHydraulic disc brake
Brake sytem codeS10
Front Brake BrandShimano
Primary Rear Brake ModelBR-MT200
Front brakeShimano BR-MT200, 180 mm
Rear brakeShimano BR-MT200, 160 mm
Rear Brake LeverBLMT200
Handlebar & Seat
Handlebar
HandlebarHerrmans DD36, plastic wear-resistant handlebar grips for a firm grasp
Stem adjustableYes
Cockpit Handlebar Grip BrandHerrmans
Saddle
SaddleDDK
Seatpost suspensionNo
Lighting
Front light
Front lightAXA Compactline 35
Front Light Energy SourceBattery
Front Light Lux35
Rear light
Rear Light Energy SourceBattery
Rear lightAXA Blueline
E-bike technology
Engine
MotorBosch Smart System Performance Line
System ModelPerformance Line
Ebike System BrandBosch Smart System
Ebike Engine PositionMid
Ebike Max Speed kmh25
Ebike Max Speed mph15
Engine Max Torque (Nm)75
Battery
ChargerBosch
Ebike Battery Charger Description2 Ah
Battery PositionIntegrated in the frame
Display
DisplayBosch Purion 200
Ebike Walk AssistYes
Display TypeLCD
Service
Warranty
Frame warranty10 year's warranty
Fork warranty5 year's warranty
Paint warranty5 year's warranty
Other parts warranty2 year's warranty
Battery warranty2 year's warranty
Motor warranty2 year's warranty
Display warranty2 year's warranty
